Factory Parking Brake Shoe Set, 90-9/91 300ZX (Z32)

Supercedes to 24-5023.

Includes:

• (1) Parking Brake Shoe Set*

Description:
Parking brake shoes are used to keep your 300ZX-Z32 in place when the parking (hand) brake is applied. When the parking brake lever is pulled up, these drum brake shoes are mechanically pushed outward against the inside of the rear brake rotors. 90-96 models were the first Z-Cars to use an "internal drum" brake configuration mounted inside of the brake rotor for the parking brake, which overall simplifies the parking brake's functionality. Separating the primary brake friction component from the parking brake also means that the parking brake can hold better even when the rear brake pads/shoes are worn. If your ZX is having trouble staying in place when the hand brake is applied, this is the first component that should be inspected. *Sold as a complete set of 4 brake shoes to cover both rear parking brakes.

Note:
These parking brake shoes do not include replacement hardware. When replacing the shoes, all of the hardware should be inspected for age and wear, and replaced as needed. Please contact us for replacement options.

Supercessions:
This part number is “superceded”. Most of our supercessions originated with Nissan. A part made for a Z31, for instance, may actually be the same as the part made for the Z32, but it was given a different number. Nissan would then later supercede the number, so that if you ordered the part number for the Z32, what you would actually get is the original part number for the Z31 (or vice-versa), as they are the same part. Other times, supercessions can exist between different parts on the same car, as is often the case with hardware of the same size. These supercessions were Nissan decisions, where replacing the “superceded from” part with the “superceded to” part results in identical performance. The vast majority of them are simple numbering changes, where the parts are literally identical. In some cases, the two parts are identical in fit and function, but the finish is slightly different, or the non-critical overall dimensions are slightly different (like one starter housing being ¼” shorter than the other on the non-attached side). They do not affect the function of the part, and in many cases, the “superceded-to” part improves upon the “superceded-from” part.

Model Guide:
Nissan 300ZX

Model Restriction:
Fits models from 90 through 9/91.

Code Guide:
Nissan Z32

Year Guide:
1990, 1991

Some parts may not fit every version of every year listed. See product Title & Description for any application breakdowns or customization options, and contact us with any questions.

• 1990 Nissan 300ZX-Z32
• 1991 Nissan 300ZX-Z32
